• Year
  • 1972/1973
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 28936

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 11
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz
  • Tuned circuits
  • 9 AM circuit(s)     10 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
  • Power type and voltage
  • Line / Batteries (any type) / 220 / 6 × 1,5 Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Power out
  • 2.5 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Galaxy-mesa 6600 973.102.A - Nordmende, Norddeutsche Mende-
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 400 x 195 x 75 mm / 15.7 x 7.7 x 3 inch
  • Notes
  • 2 ICs. 6 KW-Bänder. Ausgangsleistung bei Netzbetrieb = 3 W (Sinus).
  • Net weight (2.2 lb = 1 kg)
  • 3.1 kg / 6 lb 13.3 oz (6.828 lb)
  • Price in first year of sale
  • 328.00 DM
  • External source of data
  • Erb
