For model Rigoletto 59 Ch= 3D, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1959 perfect model Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EM84 EL84
Main principle ZF/IF 460/10700 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 5.5 W (undistorted)
from Radiomuseum.org Model: Rigoletto 59 Ch= 3D - Nordmende, Norddeutsche Mende-
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 560 x 345 x 265 mm / 22 x 13.6 x 10.4 inch
Notes

Neuere Ausführung oder Variante von Rigoletto 59/3D Ch= 59/615. Unterschied andere Anordnung des Kombi-Elkos und des Steckers zur Klangregelung.

Net weight (2.2 lb = 1 kg) 10.6 kg / 23 lb 5.6 oz (23.348 lb)
Price in first year of sale 308.00 DM

Model page created by Heinz LUCAS. See "Data change" for further contributors.
