For model Rigoletto 967.115.00 Ch= 7/615 (Ch= 867.615.00), Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1967/1968 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECC85 ECH81 EBF89 ECL86 EM84
Semiconductors (the count is only for transistors) OA79 OA79 Si-Br-Gl
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 4 AM circuit(s)     6 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 3.5 W (unknown quality)
from Radiomuseum.org Model: Rigoletto 967.115.00 Ch= 7/615 - Nordmende, Norddeutsche Mende-
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 490 x 270 x 175 mm / 19.3 x 10.6 x 6.9 inch
Notes UKW: 86,7 - 104 MHz
KW: 5900 - 18500 kHz
MW: 515 - 1650 kHz
LW: 140 - 360 kHz
Net weight (2.2 lb = 1 kg) 5.7 kg / 12 lb 8.9 oz (12.555 lb)
Collectors' prices
Source of data Handbuch VDRG 1967/1968
Mentioned in -- Original-techn. papers.

Model page created by Richard Winter. See "Data change" for further contributors.
