• Year
  • 1965–1967
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 7678

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 8
  • Main principle
  • Superheterodyne (common); ZF/IF 460 kHz
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast plus more than 2 Short Wave bands.
  • Power type and voltage
  • Storage and/or dry batteries / 6x1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
  • from Radiomuseum.org
  • Model: Rumba Ch= 5/603E - Nordmende, Norddeutsche Mende-
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 230 x 168 x 82 mm / 9.1 x 6.6 x 3.2 inch
  • Notes
  • MW: 515-1650 kHz
    KW1: 2,2-6,5 MHz
    KW2: 5,9-14 MHz
    KW3: 13,3-22,5 MHz

    Anschlüsse für Netzgerät und Ohrhörer bzw. Außenlautsprecher
  • Net weight (2.2 lb = 1 kg)
  • 2.1 kg / 4 lb 10 oz (4.626 lb)
  • Source of data
  • -- Original-techn. papers. / Radiokatalog Band 1, Ernst Erb
  • Picture reference
  • Das Modell ist im «Radiokatalog» (Erb) abgebildet.
