• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1968 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 198142

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Spectra Phonic C Ch= A121F - Nordmende, Norddeutsche Mende-

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 570 x 165 x 150 mm / 22.4 x 6.5 x 5.9 inch

• Notes
• The export model Spectra-Phonic C with chassis A121F has FM for 88 to 108 mc, but the domestic Apectra Phonic A121B has only FM for 88 to 104 mc (MHz). We find transistors like AF126, AC151 etc.

• Author
• Model page created by Ernst Erb. See "Data change" for further contributors.
