Nordmende,: TR101 981.106 [TV Radio] ID = 2068707 1400x930
Select picture or schematic to display from thumbnails on the right and click for download.
For model TR101 981.106, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1980 ?? Category: Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
Valves / Tubes 1: 60AB4
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / 6 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: TR101 981.106 - Nordmende, Norddeutsche Mende-
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Notes

Portable Multistandard VHF/UHF CCIR B/G/I/L 53-mm-TV mit Radio. Akku 6V Ladeeinrichtung, Speisung auch mit externem Netzteil möglich,
Europa Ausführung des bauähnlichen Orion TVR-7120.

Net weight (2.2 lb = 1 kg) 1.2 kg / 2 lb 10.3 oz (2.643 lb)
Literature/Schematics (1) -- Original-techn. papers.
