Transita Automatic S 49m S33 Ch= 6/603 KL49m (866.603.30)
Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
- Country
- Germany
- Manufacturer / Brand
- Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
- Year
- 1965/1966
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 7684
Nordmende Katalog
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 10
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Tuned circuits
- 7 AM circuit(s) 13 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Dry Batteries / 5 × 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
- Power out
- 2 W (unknown quality)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Transita Automatic S 49m S33 Ch= 6/603 KL49m - Nordmende, Norddeutsche Mende-
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 273 x 184 x 94 mm / 10.7 x 7.2 x 3.7 inch
- Notes
-
UKW: 87 - 104 MHz
KW: 5950 - 6200 kHz
MW: 515 - 1650 kHz
LW: 145 - 260 kHz
Betrieb im Auto über Autohalterung aus 6-V- oder 12-V-Autobatterie möglich. Netzbetrieb mit zusätzlichem Netzteil möglich.4 Ausführungen: kaviar, tabak, bordeauxrot, Teak.
- Net weight (2.2 lb = 1 kg)
- 2.8 kg / 6 lb 2.7 oz (6.167 lb)
- Source of data
- Handbuch VDRG 1966/1967 / Radiokatalog Band 1, Ernst Erb
- Literature/Schematics (1)
- -- Original-techn. papers.
- Other Models
-
Here you find 1747 models, 1640 with images and 1264 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Collections
The model Transita Automatic S 49m is part of the collections of the following members.
Forum contributions about this model: Nordmende,: Transita Automatic S 49m S33 Ch= 6/603 KL49m
Threads: 1 | Posts: 2
I have a Transita Automatic S 49m S33 with the teak housing.
Does anyone know what the difference is between the Transita Automatic and the Transita Automatic S ?
Visibly, there is an indication located at the left of the volume knob, which can be pulled upwards slightly. The indication is showing two small squares: a full white one and a diagonally divided white/black one.
Technically, I noticed some differences on the audio PCB: different values for some resistors, and a different current runaway protection circuit around trimmer R173 (featuring a thermistor and a diode).
In addition, the driver transistors Tr7 and Tr8 for the audio end transistors are no AC162 types, as indicated on the schematic, but AC151. They look original.
Can anyone tell me where the 'S' is standing for ?
Paulus van Os, 29.Jan.24
