Transita PL400 989.118H

Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Data
Forum
Pictures
Collections

  • Year
  • 1990–1992
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 238596

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Batteries / addl. power jack / AA 4 x 1,5 & AAA 2 x 1,5 / 6 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Transita PL400 989.118H - Nordmende, Norddeutsche Mende-
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 185 x 115 x 35 mm / 7.3 x 4.5 x 1.4 inch
  • Notes

  • Nordmende Transita PL400;

    Empfangsbereiche:

    LW 153-281 kHz in 1 kHz-Schritten;
    MW 531-1602 kHz in 9 kHz-Schritten;
    KW 5900-15500 kHz in 5 kHz-Schritten;
    UKW 87,5-108,0 MHz in 50 kHz Schritten.

    Beleuchtbares LCD-Display für Frequenz oder Uhrzeit; Weckfunktion;
    Sendersuchlauf; 5 Stationstasten, je 4x belegbar.
    Stromversorgung: 4x 1,5 V Mignon für Radio plus 2x 1,5V Micro f. Uhr/Speicher.
    Anschluss für ext. Stromversorgung.
    Neupreis 179,-DM im 1. Jahr, 139,-DM im 2. Jahr (lt. Franzis Taxliste).

  • Net weight (2.2 lb = 1 kg)
  • 0.450 kg / 0 lb 15.9 oz (0.991 lb)
  • Price in first year of sale
  • 179.00 DM
  • Author
  • Model page created by Boris Witke. See "Data change" for further contributors.
