Transita Royal I08 Ch= 4/608 LW, MW, UKW

Transita Royal I08 Ch= 4/608; Nordmende, (ID = 1408318) Radio

Transita Royal I08 Ch= 4/608; Nordmende, (ID = 1408320) Radio

Transita Royal I08 Ch= 4/608; Nordmende, (ID = 1408321) Radio
Transita Royal I08 Ch= 4/608; Nordmende, (ID = 1067425) Radio Transita Royal I08 Ch= 4/608; Nordmende, (ID = 105028) Radio
Transita Royal I08 Ch= 4/608; Nordmende, (ID = 1067426) Radio Transita Royal I08 Ch= 4/608; Nordmende, (ID = 1067427) Radio
Transita Royal I08 Ch= 4/608; Nordmende, (ID = 1380211) Radio Transita Royal I08 Ch= 4/608; Nordmende, (ID = 1380212) Radio
Transita Royal I08 Ch= 4/608; Nordmende, (ID = 1380213) Radio Transita Royal I08 Ch= 4/608; Nordmende, (ID = 1674521) Radio
Transita Royal I08 Ch= 4/608; Nordmende, (ID = 1674522) Radio Transita Royal I08 Ch= 4/608; Nordmende, (ID = 2030067) Radio
Use red slider bar for more.
Transita Royal I08 Ch= 4/608; Nordmende, (ID = 1067425) Radio
Nordmende,: Transita Royal I08 Ch= 4/608 [Radio] ID = 1067425 750x562
Select picture or schematic to display from thumbnails on the right and click for download.
For model Transita Royal I08 Ch= 4/608 LW, MW, UKW, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1966/1967 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF106 AF125 AF126 AF126 AF137 AC162 AC162 AC153 AC153 AA112 AA118 BA111
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / 5 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Transita Royal I08 Ch= 4/608 [LW, MW, UKW] - Nordmende, Norddeutsche Mende-
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 270 x 170 x 77 mm / 10.6 x 6.7 x 3 inch
Source of data Handbuch VDRG 1966/1967
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
