VARIO-recorder 973.427.A

VARIO-recorder 973.427.A; Nordmende, (ID = 71482) R-Player

VARIO-recorder 973.427.A; Nordmende, (ID = 71483) R-Player

VARIO-recorder 973.427.A; Nordmende, (ID = 71484) R-Player

VARIO-recorder 973.427.A; Nordmende, (ID = 71485) R-Player

VARIO-recorder 973.427.A; Nordmende, (ID = 206548) R-Player
VARIO-recorder 973.427.A; Nordmende, (ID = 2292618) R-Player VARIO-recorder 973.427.A; Nordmende, (ID = 2292619) R-Player
VARIO-recorder 973.427.A; Nordmende, (ID = 2292620) R-Player VARIO-recorder 973.427.A; Nordmende, (ID = 2292621) R-Player
VARIO-recorder 973.427.A; Nordmende, (ID = 2292622) R-Player VARIO-recorder 973.427.A; Nordmende, (ID = 206549) R-Player
Use red slider bar for more.
VARIO-recorder 973.427.A; Nordmende, (ID = 2292618) R-Player
Nordmende,: VARIO-recorder 973.427.A [R-Player] ID = 2292618 1400x1028
Select picture or schematic to display from thumbnails on the right and click for download.
For model VARIO-recorder 973.427.A, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1973/1974 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 6: 2SB175 2SB175 2SB176 2SB475 2SB475 2SB172
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 220 / 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
Power out 0.4 W (unknown quality)
from Radiomuseum.org Model: VARIO-recorder 973.427.A - Nordmende, Norddeutsche Mende-
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 169 x 69 x 246 mm / 6.7 x 2.7 x 9.7 inch
Notes Fernbedienungsmikrofon und Kunstleder-Tragetasche im Lieferumfang.
Net weight (2.2 lb = 1 kg) 1.3 kg / 2 lb 13.8 oz (2.863 lb)
External source of data Erb
Source of data Katalog RFP 1973
Literature/Schematics (1) -- Original-techn. papers.
