For model 6302, Northern Electric Co. Ltd.; Canada

Country:  Canada
Manufacturer / Brand:  Northern Electric Co. Ltd.; Canada
Year: 1951 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6BJ6 12BE6 6BJ6 6AQ6 50B5 35W4
Main principle Superhet with RF-stage; ZF/IF 455 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 110-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.25 inch = 13.3 cm
Power out 1.9 W (unknown quality)
from Radiomuseum.org Model: 6302 - Northern Electric Co. Ltd.;
Material Bakelite case
Shape Tablemodel, with any shape - general.
Notes

Built-in loop antenna.

Painted finish in different colours.

Circuit diagram reference Radio College of Canada
Literature/Schematics (1) Northern Electric Suppl. Pages 36, 37, 40

Model page created by Hans-Joachim Korn † 16.11.15. See "Data change" for further contributors.
