Audograph B1C4P

Northern Electric Co. Ltd.; Montreal, QC ; Belleville, ON

Data
Forum
Pictures
Collections

  • Year
  • 1949 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 350421

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Recording phonogr.-Disc Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 60Hz, 105-125 Volt
  • Loudspeaker
  • -Loudspeaker incorporated, but system not known. / Ø 2 inch = 5.1 cm
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Audograph B1C4P - Northern Electric Co. Ltd.;
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 9.5 x 7 x 9 inch / 241 x 178 x 229 mm
  • Notes

  • Version canadienne de Audograph inventé et produit aux États-unis par Gray Manufacturing. À noter que le modèle canadien a 5 lampes alors qu ele modèle américain en avait 4. Les disques en plastique (vinyle) sont gravés. Ce n'est pas un enregistreur magnétique. Nécessite un microphone. Peut être branché aussi sur un haut-parleur externe ou des écouteurs.

    Canadian version of Gray's Audopgraph manufactured in USA. Please note that the canadian model has 5 tubes whereas the american one had 4. This machine will emboss a plastic (vinyl) record. This is not a magnetic recorder. Requires a microphone. Can also be connected on an external speaker or earphones.

  • Net weight (2.2 lb = 1 kg)
  • 9 lb 0 oz (9 lb) / 4.086 kg
  • Author
  • Model page created by Alain Dufour. See "Data change" for further contributors.
