H45A

H45A; NSF Nederlandsche (ID = 244153) Radio H45A; NSF Nederlandsche (ID = 354533) Radio
H45A; NSF Nederlandsche (ID = 354534) Radio H45A; NSF Nederlandsche (ID = 354535) Radio
Use red slider bar for more.
H45A; NSF Nederlandsche (ID = 244153) Radio
NSF Nederlandsche: H45A [Radio] ID = 244153 450x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model H45A, NSF Nederlandsche Seintoestellen Fabriek, Hilversum

Country:  Netherlands
Manufacturer / Brand:  NSF Nederlandsche Seintoestellen Fabriek, Hilversum
Year: 1932/1933 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: E462 E462 E428 E428 C453 1823
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 125-245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: H45A - NSF Nederlandsche
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Notes Superinductance. Cassis identically constructed like Philips 630A.
Price in first year of sale 250.00 f
Mentioned in Technisch- Commercieel - Radio Vademecum Staleman

Model page created by Folkert Rothe. See "Data change" for further contributors.
