L'Océan 7 lampes
Océanic, ITT Océanic; Paris
- Country
- France
- Manufacturer / Brand
- Océanic, ITT Océanic; Paris
- Year
- 1954
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 347270
- Number of Tubes
- 7
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110-240 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 18 cm = 7.1 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: L'Océan [7 lampes] - Océanic, ITT Océanic; Paris
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 610 x 330 x 230 mm / 24 x 13 x 9.1 inch
- Notes
-
Décors plastiques frontaux et latéraux lumineux , haut-parleur Musicalpha, prises antenne-terre + PU + HPS.
Voir aussi mdèle L'Océan avec 6 lampes et 6AQ5.
- Author
- Model page created by Vincent Baccialone. See "Data change" for further contributors.
- Other Models
-
Here you find 157 models, 134 with images and 40 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Océanic, ITT Océanic; Paris
