For model Picnic (Pic Nic), Océanic, ITT Océanic; Paris:
2eme OCEANIC PICNIC

Country:  France
Manufacturer / Brand:  Océanic, ITT Océanic; Paris
Year: 1960/1961 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: 2N486 2N484 2N483 2N363 2N633 2N633
Main principle Superheterodyne (common); ZF/IF 455 kHz; 3 AF stage(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
Power out 0.15 W (unknown quality)
from Radiomuseum.org Model: Picnic - Océanic, ITT Océanic; Paris
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 170 x 98 x 40 mm / 6.7 x 3.9 x 1.6 inch
Notes

6 transistors + 1 diode. HP impédance 35 ohms.

Peut être équipé aussi de : SFT108A SFT107A SFT106A SFT152 SFT122 SFT122

Net weight (2.2 lb = 1 kg) 0.550 kg / 1 lb 3.4 oz (1.211 lb)
Price in first year of sale 239.00 FRF
Mentioned in -- Original prospect or advert
Literature/Schematics (1) Radio et Télévision, Oct. 1960

Model page created by a member from A. See "Data change" for further contributors.
