Power Supply LABPAC B504D

Power Supply LABPAC B504D; Oltronix AB; (ID = 1598422) Power-S
Power Supply LABPAC B504D; Oltronix AB; (ID = 1598373) Power-S
Use red slider bar for more.
Power Supply LABPAC B504D; Oltronix AB; (ID = 1598373) Power-S
Oltronix AB;: Power Supply LABPAC B504D [Power-S] ID = 1598373 453x784
Select picture or schematic to display from thumbnails on the right and click for download.
For model Power Supply LABPAC B504D, Oltronix AB; Vällingby:
Source: Oltronix Product Description

Country:  Sweden
Manufacturer / Brand:  Oltronix AB; Vällingby
Year: 1978 ?? Category: Power supply/conditioner or battery or charger
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Power Supply LABPAC B504D - Oltronix AB; Vällingby
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 88 x 176 x 255 mm / 3.5 x 6.9 x 10 inch
Notes

Power supply providing one variable voltage output with Digital Setting plus a fixed 5V output.

Output1: 0 - 100V at 0.5A
Output2: 5V at 1A

Net weight (2.2 lb = 1 kg) 2.9 kg / 6 lb 6.2 oz (6.388 lb)
Mentioned in -- Original prospect or advert

Model page created by Pius Steiner. See "Data change" for further contributors.
