Regulated Power Supply C50-5R

Regulated Power Supply C50-5R; Oltronix AB; (ID = 1314041) Power-S Regulated Power Supply C50-5R; Oltronix AB; (ID = 1314042) Power-S
Regulated Power Supply C50-5R; Oltronix AB; (ID = 1314043) Power-S Regulated Power Supply C50-5R; Oltronix AB; (ID = 1314044) Power-S
Regulated Power Supply C50-5R; Oltronix AB; (ID = 1314045) Power-S Regulated Power Supply C50-5R; Oltronix AB; (ID = 1314046) Power-S
Use red slider bar for more.
Regulated Power Supply C50-5R; Oltronix AB; (ID = 1314041) Power-S
Oltronix AB;: Regulated Power Supply C50-5R [Power-S] ID = 1314041 933x272
Select picture or schematic to display from thumbnails on the right and click for download.
For model Regulated Power Supply C50-5R, Oltronix AB; Vällingby:
Front view

Country:  Sweden
Manufacturer / Brand:  Oltronix AB; Vällingby
Year: 1970 ?? Category: Power supply/conditioner or battery or charger
Semiconductors (the count is only for transistors) 19:
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Regulated Power Supply C50-5R - Oltronix AB; Vällingby
Material Metal case
Shape Rack
Dimensions (WHD) 480 x 130 x 410 mm / 18.9 x 5.1 x 16.1 inch
Notes

Power supply 50V/5A with remote control.

Transistors: 3*2N1100, 2*L100, 8*2N1304, 3*2S302, 3*ACY17, 11 diodes



Net weight (2.2 lb = 1 kg) 15.3 kg / 33 lb 11.2 oz (33.7 lb)

Model page created by Anders Sandgren. See "Data change" for further contributors.
