KE150U Ch= 134
- United States of America (USA)
- Manufacturer / Brand
- Olympic Radio & Television, Inc.; New York (NY)
- Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
- Radiomuseum.org ID
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- Valves / Tubes
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 110 - 120 Volt
- 2 Loudspeakers
- from Radiomuseum.org
- Model: KE150U Ch= 134 - Olympic Radio & Television,
- 21" b/w TV, Radio, Phono Combination with US standard VHF Tuner Channels 2 thru 13, 14 thru 83 UHF. Some models use the picture tube 24AEP4.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 3-59, Set 435, Folder 2)
- Model page created by Egon Penker. See "Data change" for further contributors.
