• Country
• Japan

• Manufacturer / Brand
• Onkyo, Osaka Denki Onkyo K.K.; Osaka

• Year
• 1968 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 349036

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 10

• Semiconductors
• 2SA517 2SA518 2SA49 2SA53 2SB54 2SB54 2SB56 2SB56 2SB56 2SB56

• Main principle
• Superhet with RF-stage

• Wave bands
• Broadcast, Short Wave(s) and Police.

• Power type and voltage
• Line / Batteries (any type) / 220 or D: 4 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: AC-DC 2 Way 10PA-406 - Onkyo, Osaka Denki Onkyo K.K.;

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 304 x 193 x 94 mm / 12 x 7.6 x 3.7 inch

• Author
• Model page created by David Erali. See "Data change" for further contributors.

• Other Models

• Here you find 639 models, 616 with images and 62 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
