• Country
• Japan

• Manufacturer / Brand
• Onkyo, Osaka Denki Onkyo K.K.; Osaka

• Year
• 1990 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 241378

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• PLL, Phase-locked loop

• Wave bands
• FM Broadcast Band Only

• Details
• CD-Player, -Writer, MD, MOD (audio)

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 40 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: CD Receiver CR-185X - Onkyo, Osaka Denki Onkyo K.K.;

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 185 x 131 x 331 mm / 7.3 x 5.2 x 13 inch

• Notes

• RDS, 30 FM preeselect.

• Net weight (2.2 lb = 1 kg)
• 4.2 kg / 9 lb 4 oz (9.251 lb)

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.

• Other Models

• Here you find 638 models, 615 with images and 62 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
