Quartz Locked Direct Drive Auto-Return Turntable CP-1033A

Quartz Locked Direct Drive Auto-Return Turntable CP-1033A; Onkyo, Osaka Denki (ID = 2328853) R-Player Quartz Locked Direct Drive Auto-Return Turntable CP-1033A; Onkyo, Osaka Denki (ID = 2328854) R-Player
Quartz Locked Direct Drive Auto-Return Turntable CP-1033A; Onkyo, Osaka Denki (ID = 2328855) R-Player Quartz Locked Direct Drive Auto-Return Turntable CP-1033A; Onkyo, Osaka Denki (ID = 2328856) R-Player
Quartz Locked Direct Drive Auto-Return Turntable CP-1033A; Onkyo, Osaka Denki (ID = 2328857) R-Player Quartz Locked Direct Drive Auto-Return Turntable CP-1033A; Onkyo, Osaka Denki (ID = 2328858) R-Player
Use red slider bar for more.
Quartz Locked Direct Drive Auto-Return Turntable CP-1033A; Onkyo, Osaka Denki (ID = 2328853) R-Player
Onkyo, Osaka Denki: Quartz Locked Direct Drive Auto-Return Turntable CP-1033A [R-Player] ID = 2328853 933x920
Select picture or schematic to display from thumbnails on the right and click for download.
For model Quartz Locked Direct Drive Auto-Return Turntable CP-1033A, Onkyo, Osaka Denki Onkyo K.K.; Osaka:
Ebay.com auction item 153258724032 seller ravenrestore

Country:  Japan
Manufacturer / Brand:  Onkyo, Osaka Denki Onkyo K.K.; Osaka
Year: 1985 ?? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 120 or 220 or 240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Quartz Locked Direct Drive Auto-Return Turntable CP-1033A - Onkyo, Osaka Denki Onkyo K.K.;
Material Plastics (no bakelite or catalin)
Shape Book-shelf unit.
Dimensions (WHD) 418 x 132 x 376 mm / 16.5 x 5.2 x 14.8 inch
Notes

Two speed (33⅓, 45 rpm) automatic-return turntable.

Motor: Brushless quartz locked direct drive DC motor
Wow and Flutter:  0.025% (WRMS)
Signal to noise ratio: 75dB
Tonearm: Lightweight static balance gimbal-support pipe arm with detachable headshell (ADC  type connector) and direct readout tracking force
Overhang: 13mm (½ inch)
Cartridge: VM type OC61-V with DN-61T stylus

AC mains options:
120 Volts AC 60 Hz  model suffix UDN, UDC, UD
220 Volts AC 50 Hz  model suffix UGV, UG
240 Volts AC 50 Hz  model suffix UQA, UQB
120 or 220 Volts AC 50/60 Hz model suffix UW

Net weight (2.2 lb = 1 kg) 5.5 kg / 12 lb 1.8 oz (12.115 lb)
Source of data - - Data from my own collection
Literature/Schematics (1) - - Manufacturers Literature (Service Manual)

Model page created by Jens Ladenthin † 3.9.2012. See "Data change" for further contributors.
