• Country
• Japan

• Manufacturer / Brand
• Onkyo, Osaka Denki Onkyo K.K.; Osaka

• Year
• 1969

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 159676

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 44 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Integra 225 - Onkyo, Osaka Denki Onkyo K.K.;

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 437 x 136 x 345 mm / 17.2 x 5.4 x 13.6 inch

• Notes
• AM/FM Stereo Receiver with 22 Watts RMS per channel into 8 ohms.

• Net weight (2.2 lb = 1 kg)
• 10 kg / 22 lb 0.4 oz (22.026 lb)

• Price in first year of sale
• 62,800.00 JPY

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
