Integra P-309

Integra P-309; Onkyo, Osaka Denki (ID = 651681) Ampl/Mixer
Use red slider bar for more.
Integra P-309; Onkyo, Osaka Denki (ID = 651681) Ampl/Mixer
Onkyo, Osaka Denki: Integra P-309 [Ampl/Mixer] ID = 651681 900x298
Select picture or schematic to display from thumbnails on the right and click for download.
For model Integra P-309, Onkyo, Osaka Denki Onkyo K.K.; Osaka:
Prospekt

Country:  Japan
Manufacturer / Brand:  Onkyo, Osaka Denki Onkyo K.K.; Osaka
Year: 1983 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) 81:
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Integra P-309 - Onkyo, Osaka Denki Onkyo K.K.;
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 476 x 122 x 415 mm / 18.7 x 4.8 x 16.3 inch
Notes Stereo PreAmplifier. High Cut Filter: 7kHz, 6dB/Oct.; EQ Subsonic Filter: 15Hz/20Hz, 6dB/Oct..
Wooden Side Panels.
71 Transistors, 10 FET's, 8 IC's, 50 Diodes.
Net weight (2.2 lb = 1 kg) 10.5 kg / 23 lb 2 oz (23.128 lb)
Price in first year of sale 250'000.00 JPY

Model page created by Franz Scharner. See "Data change" for further contributors.
