MiniDisc Recorder MD-105X
Use red slider bar for more.
Onkyo, Osaka Denki: MiniDisc Recorder MD-105X [R-Player] ID = 1564717 843x1191
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1999 | Category: Sound/Video Recorder and/or Player | ||||
| Semiconductors (the count is only for transistors) | Semiconductors present. |
|---|
| Main principle | Audio-Amplification |
|---|---|
| Wave bands | - without |
| Details | Other Recorder/Player; Radio Control (+Remote Wire etc) |
| Power type and voltage | Alternating Current supply (AC) / 230 Volt |
| Loudspeaker | - For headphones or amp. |
| Power out | |
| from Radiomuseum.org | Model: MiniDisc Recorder MD-105X - Onkyo, Osaka Denki Onkyo K.K.; |
| Material | Metal case |
| Shape | Book-shelf unit. |
| Dimensions (WHD) | 205 x 76 x 287 mm / 8.1 x 3 x 11.3 inch |
| Notes | CD dubbing, 10Hz - 20 kHz +/- 0,5 dB, S/N ratio 106 dB. |
| Net weight (2.2 lb = 1 kg) | 2.3 kg / 5 lb 1.1 oz (5.066 lb) |
Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
