- Country
- Japan
- Manufacturer / Brand
- Onkyo, Osaka Denki Onkyo K.K.; Osaka
- Year
- 1981
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 145693
Original prospekt in 1981.
Original prospekt in 1981.
Onkyo Katalog 1981
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 140 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: TX-30 - Onkyo, Osaka Denki Onkyo K.K.;
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 418 x 83 x 380 mm / 16.5 x 3.3 x 15 inch
- Notes
- AM/FM-Hifi-Receiver mit 2 x 70 Watt Sinus an 4 Ohm.
- Net weight (2.2 lb = 1 kg)
- 7.8 kg / 17 lb 2.9 oz (17.181 lb)
- Source of data
- -- Original prospect or advert
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
