St. James 4 Auto Type S.2 Ch= X533-74

St. James 4 Auto Type S.2 Ch= X533-74; Optalix, T.E.D.; (ID = 1202760) Radio St. James 4 Auto Type S.2 Ch= X533-74; Optalix, T.E.D.; (ID = 1202761) Radio
St. James 4 Auto Type S.2 Ch= X533-74; Optalix, T.E.D.; (ID = 1202759) Radio St. James 4 Auto Type S.2 Ch= X533-74; Optalix, T.E.D.; (ID = 1202763) Radio
St. James 4 Auto Type S.2 Ch= X533-74; Optalix, T.E.D.; (ID = 2578996) Radio St. James 4 Auto Type S.2 Ch= X533-74; Optalix, T.E.D.; (ID = 1202762) Radio
Use red slider bar for more.
St. James 4 Auto Type S.2 Ch= X533-74; Optalix, T.E.D.; (ID = 1202760) Radio
Optalix, T.E.D.;: St. James 4 Auto Type S.2 Ch= X533-74 [Radio] ID = 1202760 900x635
Select picture or schematic to display from thumbnails on the right and click for download.
For model St. James 4 Auto Type S.2 Ch= X533-74, Optalix, T.E.D.; Amiens, Paris, Aubervilliers

Country:  France
Manufacturer / Brand:  Optalix, T.E.D.; Amiens, Paris, Aubervilliers
alternative name

TED, Technique et Décoration
Year: 1974 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: BF194 BF195 BF195 BC148 AC132 AC127 OA92 BAX13
Main principle Superheterodyne (common); ZF/IF 455 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Short Wave (SW) and Long Wave (LW) only.
Details
Power type and voltage Dry Batteries / 2 x 4.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.7 cm = 3 inch
Power out
from Radiomuseum.org Model: St. James 4 Auto Type S.2 Ch= X533-74 - Optalix, T.E.D.; Amiens, Paris
Material Leather / canvas / plastic - over other material
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 186 x 105 x 60 mm / 7.3 x 4.1 x 2.4 inch
Notes

Coffret en deux coquilles en matière moulée incassable, gainé en skai.

Type S.2 : circuit imprimé X553-74, commutation antenne-cadre.

Net weight (2.2 lb = 1 kg) 0.8 kg / 1 lb 12.2 oz (1.762 lb)

Model page created by Mark Hippenstiel. See "Data change" for further contributors.
