Studio (1) Outremer PO-OC

Studio Outremer PO-OC; Optalix, T.E.D.; (ID = 1462925) Radio

Studio Outremer PO-OC; Optalix, T.E.D.; (ID = 1462926) Radio

Studio Outremer PO-OC; Optalix, T.E.D.; (ID = 1462927) Radio

Studio Outremer PO-OC; Optalix, T.E.D.; (ID = 1462928) Radio

Studio Outremer PO-OC; Optalix, T.E.D.; (ID = 1462929) Radio
Use red slider bar for more.
Studio Outremer PO-OC; Optalix, T.E.D.; (ID = 1462925) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  France
Manufacturer / Brand:  Optalix, T.E.D.; Amiens, Paris, Aubervilliers
alternative name

TED, Technique et Décoration
Year: 1967 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: AF126 AF127 AF127 AC125 AC132 AC132 OA90
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Dry Batteries / 4 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
Power out
from Radiomuseum.org Model: Studio Outremer PO-OC - Optalix, T.E.D.; Amiens, Paris
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 315 x 200 x 125 mm / 12.4 x 7.9 x 4.9 inch
Notes

2 gammes d'ondes PO 181 à 578 m, OC 24 à 95,5 m.

Existe aussi en Type Europe PO-GO.

La première incarnation de la série Studio est aussi appelé Studio 1 (sans aucune référence dans la littérature).

Net weight (2.2 lb = 1 kg) 1.880 kg / 4 lb 2.3 oz (4.141 lb)
Mentioned in -- Original-techn. papers.

Model page created by Mark Hippenstiel. See "Data change" for further contributors.
