For model Studio S (Studio 3, Silicium) Piles PO-GO, Optalix, T.E.D.; Amiens, Paris, Aubervilliers

Country:  France
Manufacturer / Brand:  Optalix, T.E.D.; Amiens, Paris, Aubervilliers
alternative name

TED, Technique et Décoration
Year: 1970 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: BF194 BF195 BF195 BC148 AC188 AC187 OA92 OA92 BAX13
Main principle Superheterodyne (common); ZF/IF 452 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
Power out 0.4 W (unknown quality)
from Radiomuseum.org Model: Studio S Piles PO-GO - Optalix, T.E.D.; Amiens, Paris
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 315 x 200 x 125 mm / 12.4 x 7.9 x 4.9 inch
Notes

2 gammes d'ondes PO 183 à 578 m, GO 1110 à 2000 m.

Coffret en couleurs variées. Poids avec piles.

Net weight (2.2 lb = 1 kg) 1.880 kg / 4 lb 2.3 oz (4.141 lb)
Mentioned in - - Manufacturers Literature
Literature/Schematics (1) Le grand livre de la TSF (Doctsf Ref 24610)
