TO300

TO300; Optalix, T.E.D.; (ID = 2563743) Radio
TO300; Optalix, T.E.D.; (ID = 1286434) Radio TO300; Optalix, T.E.D.; (ID = 1286440) Radio
Use red slider bar for more.
TO300; Optalix, T.E.D.; (ID = 1286434) Radio
Optalix, T.E.D.;: TO300 [Radio] ID = 1286434 933x620
Select picture or schematic to display from thumbnails on the right and click for download.
For model TO300, Optalix, T.E.D.; Amiens, Paris, Aubervilliers

Country:  France
Manufacturer / Brand:  Optalix, T.E.D.; Amiens, Paris, Aubervilliers
alternative name

TED, Technique et Décoration
Year: 1970 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: BC194 BF195 BF195 BC148 AC188 AC187 OA92 OA92
Main principle Superheterodyne (common); ZF/IF 452 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Dry Batteries / 2 x 4.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: TO300 - Optalix, T.E.D.; Amiens, Paris
Material Various materials
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 270 x 175 x 78 mm / 10.6 x 6.9 x 3.1 inch
Notes

3 gammes d'ondes : OC de 5.9 à 18 MHz, PO de 520 à 1620 kHz, GO de 150 à 270 kHz. Prises antenne-auto et écouteur. HP Z = 8 ohms.

Matière plastique, dos gainé anti-choc.

Net weight (2.2 lb = 1 kg) 1.8 kg / 3 lb 15.4 oz (3.965 lb)
Mentioned in -- Schematic

Model page created by Jean-Louis Buton. See "Data change" for further contributors.
