• Country
• Spain

• Manufacturer / Brand
• Optimus; Gerona

• Year
• 1968

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 225642

• • alternative name: Pla Hermanos y Cía

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 20

• Semiconductors
• BC159 BC149 BC149 BC149 BC148 BC148 40406 40406 40407 40407 40408 40408 40409 40409 40410 40410 40411 40411 40411 40411

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 125 ; 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 140 W (170 W max.)

• Material
• Metal case

• from Radiomuseum.org
• Model: Fury 140 1324 - Optimus; Gerona

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 550 x 325 x 135 mm / 21.7 x 12.8 x 5.3 inch

• Notes

• Amplificador HIFI de 2 x 70 W Estereofonico, ó 140 W Monoaural.





• Net weight (2.2 lb = 1 kg)
• 12.5 kg / 27 lb 8.5 oz (27.533 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Marcelino Iniesta Fernandez. See "Data change" for further contributors.
