Kansas 1469

Kansas 1469; Optimus; Gerona (ID = 1183432) Ampl/Mixer

Kansas 1469; Optimus; Gerona (ID = 1183428) Ampl/Mixer

Kansas 1469; Optimus; Gerona (ID = 1183430) Ampl/Mixer

Kansas 1469; Optimus; Gerona (ID = 1183427) Ampl/Mixer
Kansas 1469; Optimus; Gerona (ID = 1183425) Ampl/Mixer
Use red slider bar for more.
Kansas 1469; Optimus; Gerona (ID = 1183425) Ampl/Mixer
Optimus; Gerona: Kansas 1469 [Ampl/Mixer] ID = 1183425 933x390
Select picture or schematic to display from thumbnails on the right and click for download.
For model Kansas 1469, Optimus; Gerona:
Datos del manual de funcionamiento

Country:  Spain
Manufacturer / Brand:  Optimus; Gerona
alternative name

Pla Hermanos y Cía
Year: 1971 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) 16: SC148 SC148 SC148 SC148 SC148 SC148 SC149 SC149 SC149 SC149 SC149 SC149 SC149 2N6099 2N3055 2N3055 F12 F16
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 125; 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 30 W (45 W max.)
from Radiomuseum.org Model: Kansas 1469 - Optimus; Gerona
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 310 x 85 x 245 mm / 12.2 x 3.3 x 9.6 inch
Net weight (2.2 lb = 1 kg) 5.2 kg / 11 lb 7.3 oz (11.454 lb)

Model page created by Marcelino Iniesta Fernandez. See "Data change" for further contributors.
