• Year
  • 1952
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 232972

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and more than two Short Wave bands.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 125; 145; 220; 240 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 19 cm = 7.5 inch
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Chantecler 621 [50 périodes] - ORA, Oradyne, Gérard & Cie,
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 580 x 293 x 230 mm / 22.8 x 11.5 x 9.1 inch
  • Notes
  • 5 gammes d'ondes: PO, GO, 3 OC dont 2 bandes étalées. Cadran miroir 3 couleurs. Prises pick-up et H.P supplémentaire.

    Ébénisterie avec applications palissandre et marquetterie.

    Voir aussi modèle Chantecler 621 pour 25 périodes.

  • Net weight (2.2 lb = 1 kg)
  • 8.9 kg / 19 lb 9.7 oz (19.604 lb)
  • Mentioned in
  • -- Original prospect or advert
