• Year
  • 1934 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 285045

 Technical Specifications

  • Number of Tubes
  • 7
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 130; 220; 240 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 21 cm = 8.3 inch
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Série O - ORA, Oradyne, Gérard & Cie,
  • Shape
  • Tablemodel, high profile (upright - NOT Cathedral nor decorative).
  • Dimensions (WHD)
  • 400 x 495 x 290 mm / 15.7 x 19.5 x 11.4 inch
  • Net weight (2.2 lb = 1 kg)
  • 15.7 kg / 34 lb 9.3 oz (34.581 lb)
  • Author
  • Model page created by Roberto Gabba. See "Data change" for further contributors.
