Deluxe - 8 - Eight Transistor HT-8041

Deluxe - 8 - Eight Transistor HT-8041; Orion Electric Co., (ID = 895496) Radio
Deluxe - 8 - Eight Transistor HT-8041; Orion Electric Co., (ID = 859964) Radio Deluxe - 8 - Eight Transistor HT-8041; Orion Electric Co., (ID = 859965) Radio
Deluxe - 8 - Eight Transistor HT-8041; Orion Electric Co., (ID = 859966) Radio
Use red slider bar for more.
Deluxe - 8 - Eight Transistor HT-8041; Orion Electric Co., (ID = 859964) Radio
Orion Electric Co.,: Deluxe - 8 - Eight Transistor HT-8041 [Radio] ID = 859964 656x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model Deluxe - 8 - Eight Transistor HT-8041, Orion Electric Co., Ltd.; Echizen-shi (Fukui):
Front

Country:  Japan
Manufacturer / Brand:  Orion Electric Co., Ltd.; Echizen-shi (Fukui)
Year: 1964 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: YET_212A YET_212A YET_425B YET_425B YET_425B 2SA329 2SB113 2SB113
Main principle Superheterodyne (common)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2 inch = 5.1 cm
Power out
from Radiomuseum.org Model: Deluxe - 8 - Eight Transistor HT-8041 - Orion Electric Co., Ltd.;
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 2.625 x 4.25 x 1.25 inch / 67 x 108 x 32 mm
Notes Red Plastic Case, Crome Grille, Civil Defence Markings on Dial.
Net weight (2.2 lb = 1 kg) 0.5 lb (0 lb 8 oz) / 0.227 kg
Source of data - - Data from my own collection

Model page created by Tom Guest. See "Data change" for further contributors.
