Marine Radiotelephone M2500

Pace Communications; Harbor City (CA)

  • Year
  • 1980 ??
  • Category
  • Commercial Transmitter & Receiver (TRX not Amateur)
  • Radiomuseum.org ID
  • 178052

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Transceiver; ZF/IF 21400 kHz; 2 AF stage(s)
  • Tuned circuits
  • 1 FM circuit(s)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Powered by external power supply or a main unit. / 13,8 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 5 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Marine Radiotelephone M2500 - Pace Communications; Harbor
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 178 x 63 x 267 mm / 7 x 2.5 x 10.5 inch
  • Notes
  • 12 canales a cristal entre 156 y 163 MHz. Un solo cristal en cada canal, incluso en canales semi-duplex. Salida adicional para P.A 5W 4 Ohms.
  • Net weight (2.2 lb = 1 kg)
  • 5 lb (5 lb 0 oz) / 2.270 kg
  • Source of data
  • - - Manufacturers Literature
