21DC4 Ch= 98D2
Packard Bell Co.; Los Angeles (CA)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Packard Bell Co.; Los Angeles (CA)
- Year
- 1957 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 272393
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 21
- Valves / Tubes
- 6BN4 6CG8 6DE6 6DE6 6DE6 6AS8 6AN8 6CM7 6AN8 12AY7 6U8 6DT6 6AQ5 6S4A 6AL5 6SC7 6DQ6 6AX4GT 1B3GT 5U4GB 21ALP4A or 21ALP4B
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 110 - 120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Wooden case
- from Radiomuseum.org
- Model: 21DC4 Ch= 98D2 - Packard Bell Co.; Los Angeles
- Shape
- Console with any shape - in general
- Notes
-
The Packard-Bell model 21DC4 is a 21" b/w TV with US standard VHF Tuner channels 2 thru 13, 14 thru 83 UHF. Equipped with chassis 98D2 and picture tube 21ALP4A or 21ALP4B.
All models are available with UHF tuning and the number is following by the suffix " U ", and they employ the same chassis with modification.
Speaker 6" x 9"
- Mentioned in
- Photofact Folder, Howard W. SAMS (SET 354, FOLDER 13, DATE 4-57)
- Author
- Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
