AM-FM Stereophonic Tuner ST-45, ST-45PA, ST-45W

AM-FM Stereophonic Tuner ST-45, ST-45PA, ST-45W; PACO Electronics Co. (ID = 1518926) Radio AM-FM Stereophonic Tuner ST-45, ST-45PA, ST-45W; PACO Electronics Co. (ID = 1518927) Radio
AM-FM Stereophonic Tuner ST-45, ST-45PA, ST-45W; PACO Electronics Co. (ID = 1518928) Radio AM-FM Stereophonic Tuner ST-45, ST-45PA, ST-45W; PACO Electronics Co. (ID = 1518929) Radio
AM-FM Stereophonic Tuner ST-45, ST-45PA, ST-45W; PACO Electronics Co. (ID = 1518930) Radio AM-FM Stereophonic Tuner ST-45, ST-45PA, ST-45W; PACO Electronics Co. (ID = 1518998) Radio
AM-FM Stereophonic Tuner ST-45, ST-45PA, ST-45W; PACO Electronics Co. (ID = 1518999) Radio
Use red slider bar for more.
AM-FM Stereophonic Tuner ST-45, ST-45PA, ST-45W; PACO Electronics Co. (ID = 1518926) Radio
PACO Electronics Co.: AM-FM Stereophonic Tuner ST-45, ST-45PA, ST-45W [Radio] ID = 1518926 933x399
Select picture or schematic to display from thumbnails on the right and click for download.
For model AM-FM Stereophonic Tuner ST-45, ST-45PA, ST-45W, PACO Electronics Co., Inc.; Glendale, NY:
aus ebay, #181209858451, Verkäufer pflavs

Country:  United States of America (USA)
Manufacturer / Brand:  PACO Electronics Co., Inc.; Glendale, NY
Year: 1960 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 13: 6BK7B ECC85 6BA6 6BA6 unknown_Magic-Eye 6AU6 6AU6 6AL5 6BA6 6BE6 6BA6 12AU7 6X4
Main principle Superhet with RF-stage
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: AM-FM Stereophonic Tuner ST-45, ST-45PA, ST-45W - PACO Electronics Co., Inc.;
Material Metal case
Shape Book-shelf unit.
Notes

Connector for optional Multiplex Adaptor.

The Paco ST-45 was availably in three ways:

  • Model ST-45 - kit with factory pre-aligned transformers, complete with gold and sating black cabinet, $84.95
  • Model ST-45PA - semi-kit with both FM and AM tuner sections factory wired, pre-aligned and calibrated, complete with cabinet, $99.95
  • Model ST-45W - factory-wired, aligned and calibrated, completely assembled, $134.95
Mentioned in -- Original prospect or advert (Radio Electronics, September 1960)

Model page created by Gottfried Silberhorn. See "Data change" for further contributors.



All listed radios etc. from PACO Electronics Co., Inc.; Glendale, NY
Here you find 18 models, 18 with images and 9 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
