RD-210SP

RD-210SP; Paeansonic; where? (ID = 2150268) Kit

RD-210SP; Paeansonic; where? (ID = 2150269) Kit
RD-210SP; Paeansonic; where? (ID = 2150265) Kit RD-210SP; Paeansonic; where? (ID = 2150266) Kit
RD-210SP; Paeansonic; where? (ID = 2150267) Kit RD-210SP; Paeansonic; where? (ID = 2153314) Kit
RD-210SP; Paeansonic; where? (ID = 2153315) Kit
Use red slider bar for more.
RD-210SP; Paeansonic; where? (ID = 2150265) Kit
Paeansonic; where?: RD-210SP [Kit] ID = 2150265 800x800
Select picture or schematic to display from thumbnails on the right and click for download.
For model RD-210SP, Paeansonic; (where?)

Country:  People's Republic of China
Manufacturer / Brand:  Paeansonic; (where?)
Year: 2010 ?? Category: Kit (Parts plus instruction) or building instructions only
Semiconductors (the count is only for transistors) CD9088 TA7642 TDA2822
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 2 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 cm = 1.6 inch
Power out
from Radiomuseum.org Model: RD-210SP - Paeansonic; where?
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 100 x 62 x 25 mm / 3.9 x 2.4 x 1 inch
Notes

FM 76 - 108 MHz.



Price in first year of sale 4.98 EUR
Source of data - - Manufacturers Literature

Model page created by a member from A. See "Data change" for further contributors.



All listed radios etc. from Paeansonic; (where?)
Here you find 1 models, 1 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
