Auto Replay Radio Monitor CQ-442EGA

Auto Replay Radio Monitor CQ-442EGA; Panasonic, (ID = 1956635) Car Radio

Auto Replay Radio Monitor CQ-442EGA; Panasonic, (ID = 1956636) Car Radio

Auto Replay Radio Monitor CQ-442EGA; Panasonic, (ID = 1956637) Car Radio

Auto Replay Radio Monitor CQ-442EGA; Panasonic, (ID = 1956638) Car Radio

Auto Replay Radio Monitor CQ-442EGA; Panasonic, (ID = 1956995) Car Radio

Auto Replay Radio Monitor CQ-442EGA; Panasonic, (ID = 1956996) Car Radio

Auto Replay Radio Monitor CQ-442EGA; Panasonic, (ID = 1957001) Car Radio

Auto Replay Radio Monitor CQ-442EGA; Panasonic, (ID = 1957005) Car Radio

Auto Replay Radio Monitor CQ-442EGA; Panasonic, (ID = 1957006) Car Radio

Auto Replay Radio Monitor CQ-442EGA; Panasonic, (ID = 1957007) Car Radio
Auto Replay Radio Monitor CQ-442EGA; Panasonic, (ID = 1956641) Car Radio
Use red slider bar for more.
Auto Replay Radio Monitor CQ-442EGA; Panasonic, (ID = 1956641) Car Radio
Panasonic,: Auto Replay Radio Monitor CQ-442EGA [Car Radio] ID = 1956641 1158x522
Select picture or schematic to display from thumbnails on the right and click for download.
For model Auto Replay Radio Monitor CQ-442EGA, Panasonic, Matsushita, National ナショナル (also tubes); Osaka:
Servicemanual

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1984 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 7: 2SC2206 2SD636 2SD636 2SC1383 2SD636 2SD636 2SD734 µPC1216 AN7256 µPC1032 HA1377 AN6130 BA1350
Main principle Superheterodyne (common); ZF/IF 450/10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 16 W (unknown quality)
from Radiomuseum.org Model: Auto Replay Radio Monitor CQ-442EGA - Panasonic, Matsushita,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 178 x 44 x 145 mm / 7 x 1.7 x 5.7 inch
Net weight (2.2 lb = 1 kg) 1.4 kg / 3 lb 1.3 oz (3.084 lb)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Richard Winter. See "Data change" for further contributors.
