Colour Television TX-21S4TP

Colour Television TX-21S4TP; Panasonic, (ID = 1613089) Television

Colour Television TX-21S4TP; Panasonic, (ID = 1613088) Television

Colour Television TX-21S4TP; Panasonic, (ID = 1613335) Television
Colour Television TX-21S4TP; Panasonic, (ID = 1612962) Television Colour Television TX-21S4TP; Panasonic, (ID = 1081289) Television
Colour Television TX-21S4TP; Panasonic, (ID = 1081290) Television Colour Television TX-21S4TP; Panasonic, (ID = 1081291) Television
Colour Television TX-21S4TP; Panasonic, (ID = 1081292) Television Colour Television TX-21S4TP; Panasonic, (ID = 1081293) Television
Use red slider bar for more.
Colour Television TX-21S4TP; Panasonic, (ID = 1612962) Television
Panasonic,: Colour Television TX-21S4TP [Television] ID = 1612962 640x613
Select picture or schematic to display from thumbnails on the right and click for download.
For model Colour Television TX-21S4TP, Panasonic, Matsushita, National ナショナル (also tubes); Osaka

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1996 ?? Category: Television Receiver (TV) or Monitor
Valves / Tubes 1:
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 6 W (unknown quality)
from Radiomuseum.org Model: Colour Television TX-21S4TP - Panasonic, Matsushita,
Material Plastics (no bakelite or catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 480 x 520 x 485 mm / 18.9 x 20.5 x 19.1 inch
Notes Screen: 51 cm. Mono. PAL B/G SECAM B/G:VHF E2-E12, H1-H2, A-H, UHF E21-E69. CATV S01-S05, S1-S10 (M1-M10), S11-S20 (U1-U10), S21-S41 (hiper). PAL 525/60: PAL D/K, SECAM D/K, VHF R1-R2, R3-R5, R6-R12, UHF E21-E69.
Net weight (2.2 lb = 1 kg) 20 kg / 44 lb 0.8 oz (44.053 lb)
Source of data -- Original prospect or advert

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
