FM-AM 9-Transistor RF-90

• Country
• Japan

• Manufacturer / Brand
• Panasonic, Matsushita, National ナショナル (also tubes); Osaka

• Year
• 1965 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 284489

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Batteries / addl. power jack / 3 x 1,5 / 4,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: FM-AM 9-Transistor RF-90 - Panasonic, Matsushita,

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 7.375 x 2.875 x 3 inch / 187 x 73 x 76 mm

• Notes

• Panasonic FM-AM Transistor Radio Model RF-90.
  Telescopic antenna
  Earphone Jack
  Woodgrain Finish

• Price in first year of sale
• 34.95 USD

• Mentioned in
• -- Original prospect or advert

• Literature/Schematics (1)
• Photofact TSM Transistor Radio Series SAMS (Folder 851 Set 7 (1966))

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
