FM/AM Digital Clock Radio Accu-Set RC-6340
Use red slider bar for more.
Panasonic,: FM/AM Digital Clock Radio Accu-Set RC-6340 [Radio] ID = 1417600 933x487
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1988 ?? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Semiconductors (the count is only for transistors) | Semiconductors present. |
|---|
| Main principle | Superheterodyne (common); ZF/IF 455/10700 kHz |
|---|---|
| Wave bands | Broadcast (BC) and FM or UHF. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110-127; 220-240 & 1 x 9 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch |
| Power out | |
| from Radiomuseum.org | Model: FM/AM Digital Clock Radio Accu-Set RC-6340 - Panasonic, Matsushita, |
| Material | Plastics (no bakelite or catalin) |
| Shape | Tablemodel with Clock ((Alarm-) Clock Radio). |
| Dimensions (WHD) | 276 x 94 x 142 mm / 10.9 x 3.7 x 5.6 inch |
| Notes | Panasonic Digital AM-FM Alarm Clock Radio Model RC-6340, also produced with the "National" brand label. Cabinet in simulated wood. Tuning ranges: FM 88 - 108 MHz, AM 530 - 1605 kHz. Power consumption 6 (8) watts. Back-up battery for clock (9 V block). Available in different mains versions: 120 V only; 110-127 / 220-240 V, 50/60 Hz; 240 V only, depending on target market.
|
| Net weight (2.2 lb = 1 kg) | 1.2 kg / 2 lb 10.3 oz (2.643 lb) |
Model page created by Franz Scharner. See "Data change" for further contributors.
