FM/AM Radio Phonograph SG-710F

FM/AM Radio Phonograph SG-710F; Panasonic, (ID = 2004407) Radio FM/AM Radio Phonograph SG-710F; Panasonic, (ID = 2004408) Radio
FM/AM Radio Phonograph SG-710F; Panasonic, (ID = 2004409) Radio FM/AM Radio Phonograph SG-710F; Panasonic, (ID = 2004411) Radio
FM/AM Radio Phonograph SG-710F; Panasonic, (ID = 2004412) Radio FM/AM Radio Phonograph SG-710F; Panasonic, (ID = 2004433) Radio
FM/AM Radio Phonograph SG-710F; Panasonic, (ID = 2005815) Radio
Use red slider bar for more.
FM/AM Radio Phonograph SG-710F; Panasonic, (ID = 2004407) Radio
Panasonic,: FM/AM Radio Phonograph SG-710F [Radio] ID = 2004407 480x568
Select picture or schematic to display from thumbnails on the right and click for download.
For model FM/AM Radio Phonograph SG-710F, Panasonic, Matsushita, National ナショナル (also tubes); Osaka:
nina egeberg

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1968 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 11: 2SA71 2SA71 2SA70 2SA70 2SA70 2SB173 2SB175 2SB176 2SB176 2SC183 2SB324 OA70 OA70 OA70 1S1211 1S1211
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)     7 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details Record Player (not changer)
Power type and voltage Batteries / addl. power jack / D: 6 x 1,5 / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: FM/AM Radio Phonograph SG-710F - Panasonic, Matsushita,
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 360 x 70 x 330 mm / 14.2 x 2.8 x 13 inch
Notes

Passend zum Gerät kann der AC-Adaptor SH-962 verwendet werden.

Price in first year of sale 238.00 DM
Mentioned in Novum K.G. Rundfunk Fernseh Phono Katalog 1968/69
Literature/Schematics (1) Handbuch für Rundfunk Fernsehen Phono 1968/69 (RFP), Verlag Funk-Kurier, Thiele

Model page created by Egon Strampe. See "Data change" for further contributors.
