GX 400M RF-966MB; Panasonic, (ID = 1044052) Radio
Panasonic,: GX 400M RF-966MB [Radio] ID = 1044052 559x548
Select picture or schematic to display from thumbnails on the right and click for download.
For model GX 400M RF-966MB, Panasonic, Matsushita, National ナショナル (also tubes); Osaka:
Bild von Jörg Krall.

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1975 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast, 2 Short Wave plus FM or UHF.
Details
Power type and voltage Other, details in remarks or not known. / 6; 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: GX 400M RF-966MB - Panasonic, Matsushita,
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 220 x 200 x 70 mm / 8.7 x 7.9 x 2.8 inch
Notes National-Panasonic GX 400M, RF-966MB 4-Band FET Tuned RF Amplifier;
Cycle dial scale with FM: 87.5 - 108 MHz,
MW: ~530 - 1600 KHz,
MB: 1.6 - 4.5 MHz,
SW: 6.0 - 18.0 MHz,
rotable ferrite antenna on top, on/off 120 minutes timer, loudness, AFC, MW local/DX, RF gain control, tone control, tuning/batt. indicator, dial light, connector for external 6 V mains adaptor, suitable AC adaptor model RD-9480B known.
Compare with coverage of GX 400 RF-966LB.
Drehbare Ferritantenne an der Oberseite, On/Off Timer, Loudness, UKW mit AFC, Anschluss für externes 6 V Netzgerät.
Mentioned in Funkschau (15/1975, S. 69)
