Minivision Colour TV TC-L3G

Minivision Colour TV TC-L3G; Panasonic, (ID = 2006542) Television Minivision Colour TV TC-L3G; Panasonic, (ID = 2006543) Television
Minivision Colour TV TC-L3G; Panasonic, (ID = 2006544) Television
Use red slider bar for more.
Minivision Colour TV TC-L3G; Panasonic, (ID = 2006542) Television
Panasonic,: Minivision Colour TV TC-L3G [Television] ID = 2006542 1400x804
Select picture or schematic to display from thumbnails on the right and click for download.
For model Minivision Colour TV TC-L3G, Panasonic, Matsushita, National ナショナル (also tubes); Osaka

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1987 ? Category: Television Receiver (TV) or Monitor
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle PLL, Phase-locked loop; none
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Storage and/or dry batteries / 6 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 cm = 1.2 inch
Power out
from Radiomuseum.org Model: Minivision Colour TV TC-L3G - Panasonic, Matsushita,
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 115 x 96 x 40 mm / 4.5 x 3.8 x 1.6 inch
Notes

A very high quality LCD Colour mini TV with backlit display and resolution of 372x376 pixel.

The model TC-L3G has a swiwel/rotating antenna plus a 3.5 mm jack for external antenna(the adapter is supplied), a 3.5 mm jack for A/V input, a 3.5 mm jack for earphones and a 3.5 mm jack for external power (power supply is supplied). Model TC-L3G is equipped with a switch to select the intercarrier frequency of PAL standards B and I (5.5 and 6.0 MHz).

The Minivision has a switch to select the frequency band between VHF (channels 2-12) and UHF (channels 21-69).

A model TC-L3D is available without the intercarrier switch.

Net weight (2.2 lb = 1 kg) 0.307 kg / 0 lb 10.8 oz (0.676 lb)

Model page created by Antonio Marra. See "Data change" for further contributors.
