Panasonic,: MW-SW1-SW2 Radio Cassette Recorder RX1530T [Radio] ID = 1671130 933x662

Select picture or schematic to display from thumbnails on the right and click for download.

For model MW-SW1-SW2 Radio Cassette Recorder RX1530T, Panasonic, Matsushita, National ナショナル (also tubes); Osaka

Country:

Japan

Manufacturer / Brand:

Panasonic, Matsushita, National ナショナル (also tubes); Osaka

Year: 1981 ??

Category: Broadcast Receiver - or past WW2 Tuner

Semiconductors (the count is only for transistors)

1: AN7220 LA4160 2SC3311

Main principle	Superheterodyne (common)
Wave bands	Broadcast plus 2 Short Wave bands.
Details	Cassette-Recorder or -Player
Power type and voltage	Line / Batteries (any type) / 110-115; 115-127; 200-220; 230-250 / 5 x 1,5 Volt
Loudspeaker	2 Loudspeakers
Power out
from Radiomuseum.org	Model: MW-SW1-SW2 Radio Cassette Recorder RX1530T - Panasonic, Matsushita,
Material	Plastics (no bakelite or catalin)
Shape	Portable set > 8 inch (also usable without mains)
Notes	Panasonic RX 1530T has two speakers: 12 cm and 2 cm diameter.

Model page created by Daniel Rosha. See "Data change" for further contributors.
