National ナショナル Super Heterodyne DX-410 スーパーヘテロダイン
Use red slider bar for more.
Panasonic,: National ナショナル Super Heterodyne DX-410 スーパーヘテロダイン [Radio] ID = 1720905 932x699
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1960 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 5: 12BE6 12BA6 12AV6 30A5 35W4 |
|---|
| Main principle | Superheterodyne (common); ZF/IF 455 kHz |
|---|---|
| Wave bands | Broadcast only (MW). |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 100 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch |
| Power out | |
| from Radiomuseum.org | Model: National ナショナル Super Heterodyne DX-410 スーパーヘテロダイン - Panasonic, Matsushita, |
| Material | Plastics (no bakelite or catalin) |
| Shape | Tablemodel without push buttons, Mantel/Midget/Compact up to 14 |
| Dimensions (WHD) | 280 x 150 x 130 mm / 11 x 5.9 x 5.1 inch |
| Notes | Wave range: 535 - 1605 Kc. Domestic model. |
| Price in first year of sale | 4'950.00 JPY |
| Mentioned in | Japan Radio Museum |
Model page created by Michael Ellery. See "Data change" for further contributors.
