National Super Phonic Stereo Ensemble SE-27A

National Super Phonic Stereo Ensemble SE-27A; Panasonic, (ID = 1915728) Radio National Super Phonic Stereo Ensemble SE-27A; Panasonic, (ID = 1915731) Radio
National Super Phonic Stereo Ensemble SE-27A; Panasonic, (ID = 1915733) Radio National Super Phonic Stereo Ensemble SE-27A; Panasonic, (ID = 1915735) Radio
National Super Phonic Stereo Ensemble SE-27A; Panasonic, (ID = 1915736) Radio
Use red slider bar for more.
National Super Phonic Stereo Ensemble SE-27A; Panasonic, (ID = 1915728) Radio
Panasonic,: National Super Phonic Stereo Ensemble SE-27A [Radio] ID = 1915728 1000x611
Select picture or schematic to display from thumbnails on the right and click for download.
For model National Super Phonic Stereo Ensemble SE-27A, Panasonic, Matsushita, National ナショナル (also tubes); Osaka:
Cortesia do Sr.Luis Azevedo

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1960 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12BE6 12BA6 12AX7 15M-P19 15M-P19
Semiconductors (the count is only for transistors) OA79 SW-05
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast plus 2 Short Wave bands.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 50/60Hz, 110; 200; 225; 250 Volt
Loudspeaker 2 Loudspeakers / Ø 16.5 cm = 6.5 inch
Power out 4 W (5 W max.)
from Radiomuseum.org Model: National Super Phonic Stereo Ensemble SE-27A - Panasonic, Matsushita,
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 805 x 758 x 410 mm / 31.7 x 29.8 x 16.1 inch
Notes

Record Changer Type BSR UA-15
Pickup Turnover, Ceramic Cartridge

SW 1: 2.3 ... 7 MHz
SW 2: 7 ... 22 MHz



Net weight (2.2 lb = 1 kg) 19 kg / 41 lb 13.6 oz (41.85 lb)
Mentioned in - - Manufacturers Literature

Model page created by João-Afonso Santos. See "Data change" for further contributors.
