Oscilloscope 15 MHz VP-5216A
Use red slider bar for more.
Panasonic,: Oscilloscope 15 MHz VP-5216A [Equipment] ID = 1661608 733x550
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1985 ?? | Category: Service- or Lab Equipment | ||||
| Valves / Tubes | 1: | ||||
|---|---|---|---|---|---|
| Semiconductors (the count is only for transistors) | Semiconductors present. |
| Wave bands | - without |
|---|---|
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 220 Volt |
| Loudspeaker | - - No sound reproduction output. |
| Power out | |
| from Radiomuseum.org | Model: Oscilloscope 15 MHz VP-5216A - Panasonic, Matsushita, |
| Material | Metal case |
| Shape | Tablemodel, with any shape - general. |
| Dimensions (WHD) | 260 x 178 x 430 mm / 10.2 x 7 x 16.9 inch |
| Net weight (2.2 lb = 1 kg) | 6.2 kg / 13 lb 10.5 oz (13.656 lb) |
Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
