For model R-357D, Panasonic, Matsushita, National ナショナル (also tubes); Osaka

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1970 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 12: 2SA341 2SA101 2SA101 2SB175 2SB173 2SB173 2SB175 2SB175 2SB176 2SB176 2SB176 2SB176 OA90 OA90 1S1211 1S1211
Main principle Superheterodyne (common); ZF/IF 455 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Dry Batteries / 3 x 1,5 Volt
Loudspeaker 2 Loudspeakers / Ø 9 cm = 3.5 inch
Power out
from Radiomuseum.org Model: R-357D - Panasonic, Matsushita,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 265 x 145 x 55 mm / 10.4 x 5.7 x 2.2 inch
Notes National Panasonic R-357D, 12-Transistor 4-Diode 2-Speaker;
SW1: 2.3 - 7 MHz, SW2: 7 - 22 MHz, dial light, tuning/batt. indicator, fine tuning, tone switch, volume dial window, earphones jack, suitable brown leather case known.
Net weight (2.2 lb = 1 kg) 1.3 kg / 2 lb 13.8 oz (2.863 lb)
Source of data -- Original-techn. papers.
